1. Crystallography and Material Fundamentals of Silicon Carbide
1.1 Polymorphism and Atomic Bonding in SiC
(Silicon Carbide Ceramic Plates)
Silicon carbide (SiC) is a covalent ceramic substance composed of silicon and carbon atoms in a 1:1 stoichiometric proportion, distinguished by its remarkable polymorphism– over 250 well-known polytypes– all sharing solid directional covalent bonds yet varying in piling series of Si-C bilayers.
One of the most technologically pertinent polytypes are 3C-SiC (cubic zinc blende structure), and the hexagonal types 4H-SiC and 6H-SiC, each displaying subtle variants in bandgap, electron mobility, and thermal conductivity that influence their viability for specific applications.
The stamina of the Si– C bond, with a bond power of roughly 318 kJ/mol, underpins SiC’s remarkable firmness (Mohs firmness of 9– 9.5), high melting point (~ 2700 ° C), and resistance to chemical deterioration and thermal shock.
In ceramic plates, the polytype is generally picked based on the meant use: 6H-SiC prevails in architectural applications because of its ease of synthesis, while 4H-SiC controls in high-power electronic devices for its exceptional charge carrier flexibility.
The vast bandgap (2.9– 3.3 eV depending upon polytype) additionally makes SiC an exceptional electrical insulator in its pure form, though it can be doped to work as a semiconductor in specialized digital gadgets.
1.2 Microstructure and Stage Purity in Ceramic Plates
The performance of silicon carbide ceramic plates is seriously dependent on microstructural features such as grain size, thickness, stage homogeneity, and the visibility of second stages or impurities.
High-quality plates are normally fabricated from submicron or nanoscale SiC powders with innovative sintering strategies, resulting in fine-grained, fully thick microstructures that take full advantage of mechanical strength and thermal conductivity.
Impurities such as free carbon, silica (SiO â), or sintering help like boron or light weight aluminum have to be thoroughly managed, as they can create intergranular films that reduce high-temperature stamina and oxidation resistance.
Residual porosity, also at low degrees (
